Network YAML file

The “network.yaml” file is mandatory. It is used to specify the network module.

The network module is simply a compound module with no ports that represents the whole network topology to be simulated in the experiments.

The file is a dictionary with one key “network” that contains a list with one dictionary. The dictionary in the list represents the network module to be generated.

The format of this file is as follows:

network:
  - name: "Network"
    submodules:
      [...]  # submodules definition
    connections:
      [...]  # connections definition

As you can already imagine, it is very similar to the “compound.yaml” file format. Thus, we won’t repeat the explanation of all the keys here.

Let’s proceedby showing how a “network.yaml” file looks like. We continue the example from the “compound.yaml” file: The network connects the two Local Area Networks (LANs) together through a router:

network:
  - name: "Network"  # any name can be used
    submodules:
      - name: "router"
        type: "RouterModule"
        parameters:
          num_ports: 100
      - name: "subnet1"
        type: "LocalAreaNetwork1"
      - name: "subnet2"
        type: "LocalAreaNetwork2"
    connections:
      - source: "router.lan0"
        target: "subnet1.lan0"
        channel: "default"
        delay: 10  # [ms]
      - source: "router.lan1"
        target: "subnet2.lan0"
        channel: "default"
        delay: 5  # [ms]
